LED Flat Panel Light Dimmable 40W Ultra Slim
Quick Detail:
| Input | Luminous | CRI | Beam Angel | Lifespan | Dimmable |
| AC 100V-240V, 50/60Hz | 4000LM | >80 RA | 1200 | ≧35000Hrs | Yes,1-10V Dimming |
Description:
As a professional LED light bulb manufacturer, MingFeng are specializing in providing flat panel light for customer from all over the world.
The 40W LED dimmable panel light, using the newest LED technology. It has the excellent design, our product can be 30% heavier than common product, at the same time we can get a better heat dissipation.we use Mitsubishi LGP, it has 90% light transmittance and good light distrition. We choice Epistar or LumenMax chip to make sure our prouducts has high lumen, high CRI, and long life span. Whats more, our unique design, constant IC driver and stable make it getting perfect.
Specifications:
Optical parameters
Light Source: SMD 4014
CCT: 3000K/4000K/5000K
CRI: >80RA
Beam Angle: 120°
SDCM: <5
Lifespan: >=3500 Hrs
Electrical parameters
Power Input/frequency: AC 100-240V, 50/60Hz
Dimmable:Yes,1-10V Dimming
Power Factor(PF): >0.9
Start Time: =0.5 S
Mechanical parameters
Material: AL frame + PMMA LGP + PS Diffuser
IP Rating: IP 40
Others
Working Temperature & Humidity: -25℃~50℃, 10%~90% R.H.
Storage temperature & Humidity: -40℃~85℃, 40%~80% R.H.
Certificate: GS, TUV, CE, RoHS, CB, SAA
Features:
Details:
Alu body: Excellent design, thinkness Alu body, better heat dissipation.
Alu PCB board: Longer lifespan and better dissipation than FPC PCB.
Chip: Epistar or LumenMax Chip, high lumen, high CRI, long lifespan.
Light Guide Plate: Mitsubishi LGP, 90% Light Transmittance,good light distribution.
PMMA Diffusion Plate: MITSUBISHI PMMA Plate, high light transmittance, light is more soft and no glare.
Reflective: Highly bright reflective film.
Package:
2 PCS / INNER PACKING 6 PCS / OUTER PACKING
Applications:
Commercial, Decorative, Residential.
